Mark-10 M5i Advanced Force/Torque Indicator

The Mark-10 M5i Advanced Force/Torque Indicator is a powerful and highly adaptable device designed for accurate measurement of both force and torque. Utilizing Plug & Test™ technology, the M5i offers true interchangeability with a wide range of Mark-10 remote sensors, ensuring flexibility across various testing applications. This advanced indicator can handle tension, compression, and torque measurements with unparalleled precision, thanks to its 7,000 Hz sampling rate—ideal for fast-action tests.

Key Features:

• Interchangeable Sensors: Compatible with Mark-10’s remote force and torque sensors, all calibration and configuration data is stored within the sensor’s smart connector, not the indicator, allowing easy sensor swapping.

• Sensor and Key Password Protection: Prevent unauthorized use with built-in password protection for both sensor access and individual key calibration, ensuring the security of the device.

• High-Speed Sampling: The 7,000 Hz sampling rate ensures fast, accurate readings for both force and torque measurements.

• Versatile Output Options: Transfer data easily via USB, RS-232, Mitutoyo (Digimatic), or analog outputs, making the M5i compatible with various data collection systems.

• Data Storage and Statistical Analysis: The device offers on-board memory for up to 1,000 readings, along with statistical calculations that include min, max, mean, and standard deviation, which can be output to a PC for further analysis.

• Pass/Fail Testing: Integrated set points with indicators and outputs are perfect for pass/fail testing, making it ideal for quality control applications and for triggering external devices like alarms, relays, or test stands.

• Graphical Load Bar: A real-time analog load bar is displayed on the screen, providing a graphical representation of the applied force or torque.

• Averaging Mode: This feature allows users to capture the average load over time, useful for applications requiring continuous force or torque measurements.

• External Trigger Mode: Simplifies switch activation testing, ensuring highly accurate and repeatable results
