Mark-10 M5-50 Force Gauge

The Mark-10 M5-50 Advanced Digital Force Gauge is designed for precise tension and compression force testing, with a capacity of 50 lbf (250 N). Ideal for demanding applications across various industries, this gauge combines accuracy, speed, and advanced functionality to deliver reliable performance in both handheld and test stand setups.

Key Features:

• High-Speed Sampling: The M5-50 boasts a 7,000 Hz sampling rate, ensuring fast and accurate force measurements, even in dynamic testing scenarios.

• Data Transfer: Easily transfer data to a PC or other data collectors via USB, RS-232, Mitutoyo (Digimatic), or analog outputs, providing flexibility for data management and analysis.

• On-Board Memory: The gauge can store up to 1,000 readings, along with built-in statistical calculations such as min, max, mean, and standard deviation, streamlining your testing process.

• Live Load Bar Graph: A graphical load bar with set point markers displays the real-time force applied to the gauge, helping users monitor load limits visually.

• Programmable Set Points: Integrated set points with indicators are ideal for pass-fail testing, and can trigger external devices like alarms, relays, or test stands.

• Averaging Mode: Calculates average force over time, which is especially useful for applications like peel testing or where continuous force measurement is required.

• External Trigger Mode: Simplifies switch activation testing by remotely stopping display updates, enhancing accuracy and repeatability.

• Configurable Alarms and Tones: Audio alarms and key tones can be customized to suit operator preferences, ensuring a user-friendly experience.

• Password Protection: Prevent unauthorized access to individual keys and calibration settings with configurable password protection.

Specifications:

• Accuracy: ±0.1% of full scale

• Capacity: 50 lbf (250 N)

• Sampling Rate: 7,000 Hz for fast and accurate measurements

• Power: Operates on AC or a rechargeable battery, with up to 7 hours of continuous use with the backlight on, or 24 hours with the backlight off.

• Measurement Units: lbF, ozF, gF, kgF, N, kN, mN

• Safe Overload: Can withstand up to 200% of full scale, with an overload warning displayed at 110%.
