Mark-10 M5-025 Force Gauge

The Mark-10 M5-025 Advanced Digital Force Gauge is designed for precise tension and compression force testing in a wide range of applications. With a capacity of 0.25 lbf (1 N), this versatile gauge is ideal for industries that require accurate and reliable force measurements. The M5-025 offers easy menu navigation for quick access to its many advanced features and configurable parameters.

Key Features:

• High-Speed Sampling: The M5-025 features a 7,000 Hz sampling rate for fast, accurate readings, making it suitable for dynamic testing.

• Data Transfer: Data can be transferred to a PC or data collector via USB, RS-232, Mitutoyo (Digimatic), or analog outputs for versatile connectivity.

• On-Board Memory: Stores up to 1,000 readings, with built-in statistical calculations (min, max, mean, and standard deviation) for comprehensive data analysis.

• Live Load Bar Graph: A graphical load bar with set point markers provides a real-time visual representation of the applied force.

• Programmable Set Points: Ideal for pass-fail testing, the integrated set points trigger alarms or external devices such as a test stand or relay.

• Averaging Mode: Calculates average force over time, useful for applications like peel testing.

• External Trigger Mode: Simplifies switch contact testing by remotely stopping the display update.

• Configurable Alarms: Audio alarms and key tones are configurable to suit the operator's needs.

• Password Protection: Protects individual keys and calibration from unauthorized use.
