Mark-10 M4-50 Digital Force Gauge

The Mark-10 M4-50 Digital Force Gauge is designed for accurate measurement of both tension and compression forces, with a capacity of 50 lbf (250 N). Ideal for a variety of applications, this gauge provides peak load readings on a large, backlit LCD display for easy monitoring. The intuitive design ensures seamless operation, and data transfer can be performed via USB, RS-232, Mitutoyo (Digimatic), or analog outputs.

Key Features:

• Measurement Capacity: 50 lbf (250 N)

• High-Speed Sampling: 3,000 Hz for fast, accurate force measurements

• Output Options: USB, RS-232, Mitutoyo (Digimatic), and analog outputs

• On-Board Memory: Stores up to 50 readings, with statistical calculations including min, max, mean, and standard deviation

• Live Load Bar Graph: Displays real-time load with set point markers for visual feedback

• Set Points and Alarms: Programmable set points with alarms and outputs for triggering external devices such as alarms or relays

• Five Selectable Units of Measurement: lbF, ozF, gF, kgF, N

• Configurable Audio Alarms and Key Tones: For enhanced user feedback during operation

• Password Protection: Configurable security for individual keys and calibration

Compatible with Mark-10 Test Stands, Grips, and Software: Easily integrates into your existing testing setup
