Mark-10 M4-10 Digital Force Gauge

The Mark-10 M4-10 Digital Force Gauge is a versatile and reliable tool designed for measuring both tension and compression forces, with a capacity of 10 lbf (50 N). It is ideal for a wide range of applications, offering fast, accurate force measurements with easy data transfer options and an intuitive user interface.

Key Features:

• Measurement Range: The M4-10 has a capacity of 10 lbf (50 N) with high precision, making it suitable for various tension and compression testing applications.

• High-Speed Sampling Rate: With a 3,000 Hz sampling rate, the M4-10 provides fast, reliable measurements, even in dynamic testing scenarios.

• Data Transfer: Easily transfer data to a PC or other devices using USB, RS-232, Mitutoyo (Digimatic), or analog outputs, allowing for flexible integration into data collection systems.

• On-Board Memory: The gauge can store up to 50 readings, with built-in statistical calculations including min, max, mean, and standard deviation for efficient data analysis.

• Live Load Bar Graph: A graphical load bar with set point markers provides a real-time visual representation of the applied force, helping to monitor load levels and avoid overloads.

• Programmable Set Points: Integrated set points are ideal for pass-fail testing, and can trigger external devices like alarms, relays, or test stands, streamlining quality control processes.

• Peak Readings and Set Points Always Displayed: Peak force and set point indicators remain visible on the screen during testing, ensuring you never miss important data.

• Multiple Units of Measurement: The gauge offers five selectable units of measurement: lbF, ozF, gF, kgF, and N, giving users flexibility in their testing requirements.

• Configurable Audio Alarms and Key Tones: Customizable audio alarms and key tones enhance user feedback and improve the testing experience.

• Password Protection: The M4-10 offers password protection for individual keys and calibration settings, ensuring security during operation.

Specifications:

• Accuracy: ±0.2% of full scale

• Sampling Rate: 3,000 Hz

• Power: Operates using AC power or a rechargeable battery, providing up to 7 hours of continuous use with the backlight on, and 24 hours with the backlight off.

• Measurement Units: lbF, ozF, gF, kgF, N

• Safe Overload: Can handle up to 200% of full scale, with an overload warning displayed at 110%.
