LOCTITE 98666 Digital Syringe Dispenser

LOCTITE® Digital Syringe Dispenser 883976 Overview

The LOCTITE® Digital Syringe Dispenser 883976 is a state-of-the-art, semi-automatic system engineered specifically for the precision dispensing of LOCTITE adhesives and fluids. This unit is compatible with 3, 5, 10, 30, 55 syringes, and 300 ml cartridges. Its advanced digital timing control offers refined adjustments up to 0.001 seconds, ensuring superior accuracy compared to typical pressure-time systems. With its adjustable pressure regulator, the system controls an air pulse. Paired with an air line adapter on an adhesive syringe barrel, it consistently dispenses the precise amount of adhesive. Users can choose from manual, incremental, or timed (automatic) dispense modes for versatile application methods, including dots, beads, or syringe filling.

Notable Features:

• Drip & String Control: Vacuum suck-back effectively prevents product dripping or stringing.
• Versatile Modes: Offers Manual, Incremental, or Timed dispensing methods.
• Teach Mode: Easily set the time needed for your desired dispense amount or volume.
• Visible Cycle Counter: A clear LCD screen displays the cycle count.
• PLC Integration: Seamlessly integrate the unit into existing PLC programming for dispensing.
• Included Accessories: Comes with Foot Switch # 902521.

Technical Specifications:

• Dimensions: 152 mm (W) x 165 mm (D) x 178 mm (H)
• Weight: 1.2 kg (2.6 lbs)
• Input Voltage: 24 VDC
• Air Input/Output: Up to 7 bar (100 psi)
• Timer Range: 0.02 – 60.00 seconds
• Cycle Modes: Manual, Incremental, or Timed

Items Provided:

• Universal Power Cord and Adapter
• Foot Switch

Optimize precision tasks with the LOCTITE® Digital Syringe Dispenser 883976, crafted for reliability and accuracy.

(All Clearance Sold as Untested)
