Isaac HD Modular Production Air Leak Tester

Product Specifications:

• Compact Dimensions: 6″ wide, 7″ high, 9″ deep – A small footprint that maximizes your lab or automation space.

• High Resolution: .00001 PSI sensitivity – Ensures precise measurements to keep your parts within manufacturing specifications.

• Test Port Fitting: 1/8 FNPT female bulkhead – Compatible with common leak tester fittings such as Male Luer, Female Luer Lock, and compression fittings.

• Pressure Range: 0–15, 0–100, 0–300, 0–500, 0–1000 PSIG (Positive Pressure) or 0–14.5 PSI (Vacuum) – Automated pressure control allows for running multiple tests at varying pressures without manual adjustments.

• Valves: Type 1 – Various valve options available for customization.

• User-Friendly Display: 4.3″ color touchscreen – High definition for easy readability, with an intuitive interface that simplifies test setup.

• Customizable Configurations: Tailored setups available to meet specific application needs, ensuring relevance to your operations.

• Versatile Test Types: Pressure Decay, Vacuum Decay, Occlusion, Mass Flow, Burst, Chamber, Pressure Cracking – Minimize testing costs and maximize floor space with a tester capable of handling various tests.

• Stored Programs: Up to 100 programs – Run multiple test parameters through each port efficiently.

• Media Compatibility: Suitable for clean, dry, non-corrosive gases – Compatible with Aluminum and 316 stainless steel. Alternative solutions available for other media types.

• Communication Options: USB, RS232, I/O, Ethernet (TCP/IP), with optional EtherNet/IP – Flexible communication for diverse application needs.

• Internal Volume: 0.8 cm³ – Small internal volume minimizes testing variability, such as thermal drift.

• Calibration Accuracy: 0.25% of full scale – Provides high accuracy at an affordable price.

This system offers a versatile, compact, and highly accurate solution for various leak testing applications.
