Chatillon DFE2-200 Digital Force Gauge

Chatillon® DFE2-200 Digital Force Gauge

The Chatillon® DFE2-200 Digital Force Gauge is a versatile, compact instrument designed for accurate force measurement in both handheld and test stand applications. Ideal for economy applications without sacrificing performance, the DFE2-200 features an integral load cell with a measurement accuracy better than 0.25% of full scale, ensuring reliable and repeatable results.

The device supports various standard functions such as normal and peak readings, high/low limits, pass/fail results, and statistical data. Its high-resolution, full-color LCD display provides easy readability and can be inverted or hidden for operator convenience. Loads are displayed in multiple units including lbf, kgf, N, gf, and ozf, making it adaptable for different applications.

Key Specifications:

• Model: DFE2-200

• Capacity: 200 x 0.1 lbf, 100 x 0.1 kgf, 1000 x 1 N

• Accuracy: ±0.25% of Full Scale

• Resolution: 1000:1

• Overload Protection: 150% of Rated Capacity

• Tare Capacity: 10% of Rated Capacity

• Peak Capture Rate: 7000 Hz

• Data Sampling: 7 KHz

• Data Storage: Up to 20 Results

• Power Source: Rechargeable Nickel Metal Hydride battery (20-hour life with dimming ON) or direct AC 120/230V

• Operating Temperature: 40°F to 110°F (5°C to 45°C)

• Outputs: RS232, USB, and +2V analog output

• Language Interfaces: English, Spanish, French, German, Portuguese, and Chinese
