Chatillon DFE2-025 Digital Force Gauge

The Chatillon® DFE2-025 Digital Force Gauge is a cutting-edge tool in the field of digital force measurement, offering high performance at an economical price without sacrificing functionality. Specifically designed for both handheld and test stand applications, the DFE II Series force gauge is an excellent choice for various industrial and quality control settings.

Key Features:

• Accuracy: The DFE2-025 boasts a measurement accuracy of better than 0.25% full scale, making it highly reliable for precision tasks.

• Load Capacity: It can measure up to 25 lbf with a resolution of 0.01 lbf, ensuring fine measurement details.

• Integral Load Cell: The force gauge features an integral load cell with mechanical overload protection, capable of handling up to 150% of the rated capacity.

• High-Resolution Display: A full-color, easy-to-read LCD display offers clear visibility of readings in units such as ozf, gf, lbf, kgf, and N. The display is invertible and customizable to hide or show certain results as needed.

• Multiple Outputs: The DFE2-025 supports both digital (RS232, USB) and analog (+2V) outputs, making it highly adaptable to various communication systems. It is compatible with Chatillon test stands and other external devices.

• Peak Capture and Data Storage: The device captures peaks at a rate of 7000 Hz and allows data sampling at 7 KHz. Additionally, it can save up to 20 results, streamlining data handling and reporting.

• User-Friendly Interface: The interface is designed with ease of use in mind, featuring a dynamic keypad, navigation pod, and an “i” key that offers critical device information like battery life and calibration details.

Battery Life: The device is powered by a Nickel Metal Hydride battery, providing up to 20 hours of use with dimming on and 16 hours with dimming off. It can also be powered directly via AC.
