Dymax BlueWave 200 V1.1

The Dymax BlueWave® 200 V1.1 is a high-intensity UV light-curing spot lamp, carefully designed for curing adhesives, coatings, and potting materials. With its sleek design and versatile functionality, it offers both professionals and hobbyists a robust tool for various curing applications.

Key Features:

• High-Intensity UV Light: Emitting UV light from a lightguide (sold separately), this system is perfect for applications requiring precise curing.
• Versatile Usage: The lightguide can be hand-held for complete mobility, clamped into position for repetitive tasks, or even integrated into automated equipment for specialized operations.
• Durable Construction: The unit is encased in an anodized aluminum housing, providing durability and protection to the electronic power supply, circuit protection, bulb/reflector assembly, and other essential components.
• Cooling System: A thermostatically controlled cooling fan ensures optimum operating temperature. Fan filters should be frequently changed or cleaned to prevent blockage and reduced ventilation airflow. It's important to note that the cooling fan must not be covered or blocked.
• Patented Intensity Control: Unique to this model is the patented intensity control, allowing operators to manually adjust the output intensity to compensate for bulb degradation. This ensures consistent results during both process validation and production.
• Bulb Technology: The unit employs a 200-Watt short-arc mercury-vapor bulb, mounted in a reflector and pre-focused to provide the optimum light output. Rated for continuous operation, it stands up to demanding industrial applications.
• Shutter System: Electric shutters are included, with both timed and manual shutter operating modes, giving users the flexibility to control exposure precisely.
• Safety Measures: The BlueWave 200 V1.1 is equipped with a thermal shutdown sensor for internal temperature control, and a bulb status indicator light. If the bulb extinguishes due to a momentary power failure, the unit needs to be turned off, cooled, and then restarted.
• Power Compatibility: Operating on line voltages of 115 – 230V~, 50/60Hz, 2.5A, the system is compatible with a wide range of power supplies.

(Comes with Light Guide and accessories)

(All Clearance Items Sold as Untested)

Manual: https://dymax.com/content/download/3486/file/bluewave_200ce_v1.1%20%28discontinued%201.28.14%29.pdf
